1) 8 parameters (ECG, RESP, SPO2, NIBP, PR, TEMP, IBP, ETCO2)+Fully independent module ( Independent ECG + Nellcor);
2) Modular patient monitor, flexible to meet the different monitoring requirements;
3) Flexible operate ETCO2 and dual IBP functions;
4) 12.1 inch color LCD touch screen supports multi-lead 8-channel waveform display on the screen and support multi-language system，Full touch screen selectable, more convenient for operation;
5) Patient info input management function;
6） 400 groups of NIBP list, 6000 seconds ECG waveform recall, 60 alarm evens records recall, 7-day trend chart in storage;
7）Built-in high capacity lithium battery (4 hours) for emergency power outage or patient transfer;
8）Real time S-T segment analysis, pace-maker detection;
9）Support diagnosis, monitoring, surgery three monitoring modes, support wire or wireless central monitoring system;
10）Built-in high capacity lithium battery (4 hours) for emergency power outage or patient transfer.
1) Wireless integration with the central monitoring
2) station Dynamic trends provide up to 240 hours of useful information for viewing
3) 8 tracks per monitor, 16 monitors on one screen
4) View up to 32 beds in real time on one platform
5) View and manage patient data anytime, anywhere in and before the hospital
1) Spo2 sensor & extend cable 1pcs
2) ECG cable 1pcs
3) Cuff &Tube 1pcs
4) Temp probe
5) Power Cbale Line 1pcs
6) Ground Line 1pcs
7) User Manual 1pcs
|
ECG
|
NIBP
|
||
|
Input
|
3/5 wire ECG cable
|
Test method
|
Oscillometer
|
|
Lead section
|
I II III aVR, aVL, aVF, V
|
Philosophy
|
Adult, Pediatric and Neonate
|
|
Gain selection
|
*0.25, *0.5, *1, *2，Auto
|
Measurement type
|
Systolic Diastolic Mean
|
|
Sweep speed
|
6.25mm/s, 12.5mm/s, 25mm/s, 50mm/s
|
Measurement parameter
|
Automatic, Continuous measurement
|
|
Heart rate range
|
15-30bpm
|
Measurement method Manual |
mmHg or ±2%
|
|
Calibration
|
±1mv
|
||
|
Accuracy
|
±1bpm or ±1% (select the bigger data)
|
||
|
SPO2
|
2-Temperature (Rectal & Surface)
|
||
|
Display Type
|
Waveform, Data
|
Number of channels
|
2 channels
|
|
Measurement range
|
0-100%
|
Measurement range
|
0-50℃
|
|
Accuracy
|
±2% (between 70%-100%)
|
Accuracy
|
±0.1℃
|
|
Pulse rate range
|
20-300bpm
|
Display
|
T1, T2, ☒T
|
|
Accuracy
|
±1bpm or ±2% (select the bigger data)
|
Unit
|
ºC/ºF selection
|
|
Resolution
|
1bpm
|
Refresh cycle
|
1s-2s
|
|
Respiration (Impedance & Nasal Tube)
|
|||
|
Measurement type
|
|||
|
Accuracy
|
±1bm or ±5%, select the bigger data
|
||
|
Resolution
|
1rpm
|
||
|
Standard accessories
|
|||
|
NIBP cuff & tube
|
ECG cable & electrodes
|
SpO2 sensor
|
TEMP probe
|
|
Lithium-ion battery
|
Power cable
|
Operator’s manual
|
|
|
Optional accessories
|
|||
|
IBP
|
CO2
|
Nellcor SpO2
|
Printer
|
