| Quality Standards and Classification | |
| Anti-electroshock degree: | ClassⅠequipment (internal power supply) |
| TEMP/SpO 2 /NIBP： | BF |
| ECG/Resp: | CF |
| Trend data length | |
| School limit list ： | 400 groups |
| Waveform playback ： | 6000 seconds |
| Trend table ： | 7 days |
| Trend graph： | up to 7 days |
| Alarm review： | 60 groups |
| Electrical Specifications | |
| Power supply voltage: | AC 100~240V AC |
| Power frequency: | 50/60Hz |
| Maximum input power: | 70VA |
| Working method: | continuous work |
| Built-in lithium battery: | d.c11.1V not less than 2000mA, working time not less than 2 hours |
1) Wireless integration with the central monitoring
2) station Dynamic trends provide up to 240 hours of useful information for viewing
3) 8 tracks per monitor, 16 monitors on one screen
4) View up to 32 beds in real time on one platform
5) View and manage patient data anytime, anywhere in and before the hospital
1、NIBP cuff & tube
2、ECG cable & electrodes
3、SpO 2 sensor
4、TEMP probe
5、Lithium-ion battery
6、Power cable
7、Operator’s manual
1、End-tidal CO2 (optional)
2、Recorder (optional)
3、Dual IBP, Nellcor (optional)
|
ECG |
|
|
Input |
3/5 wire ECG cable |
|
Lead section |
I II III aVR, aVL, aVF, V |
|
Gain selection |
*0.25, *0.5, *1, *2, Auto |
|
Sweep speed |
6.25mm/s, 12.5mm/s, 25mm/s, 50mm/s |
|
Heart rate range |
15-30bpm |
|
Calibration |
±1mv |
|
Accuracy |
±1bpm or ±1% (select the bigger data) |
|
NIBP |
|
|
Test method |
Oscillometer |
|
Philosophy |
Adult, Pediatric and Neonate |
|
Measurement type |
Systolic Diastolic Mean |
|
Measurement parameter |
Automatic, Continuous measurement |
|
Measurement method Manual |
mmHg or ±2% |
|
SPO2 |
|
|
Display Type |
Waveform, Data |
|
Measurement range |
0-100% |
|
Accuracy |
±2% (between 70%-100%) |
|
Pulse rate range |
20-300bpm |
|
Accuracy |
±1bpm or ±2% (select the bigger data) |
|
Resolution |
1bpm |
|
Temp (Rectal & Surface) |
|
|
Number of channels |
2 channels |
|
Measurement range |
0-50℃ |
|
Accuracy |
±0.1℃ |
|
Display |
T1, T2, TD |
|
Unit |
ºC/ºF selection |
|
Refresh cycle |
1s-2s |
|
Resp (Impedance & Nasal Tube) |
|
|
Measurement type |
0-150rpm |
|
Accuracy |
+-1bm or +-5%, select the bigger data |
|
Resolution |
1rpm |
|
PR |
|
|
Measurement and alarm range: |
30 ~ 250 bpm |
|
Measurement accuracy: |
±2 bpm or ±2% |
|
Packing Information |
|
|
Packing size |
370mm*162mm*350mm |
|
N.W. |
5kg |
|
G.W. |
6.8kg |
