(1) 12.1-inch TFT color LCD display.
(2) Suitable for Adult, Children in ambulances,operating rooms.
(3) Multi- channel waveform display.
(4) ST segment analysis.
(5) Alarms sound and light can be set.
(6)Record and return electrocardiogram waveform.
(7)Built-in rechargeable lithium battery.
(8)With data power-off storage function.
(9)Anti-fibrillation, anti-high-frequency electrosurgical interference.
(10)Three-application mode: monitoring,diagnosis, operating.
(11)Network connection and center monitor system.
1) Wireless integration with the central monitoring
2) station Dynamic trends provide up to 240 hours of useful information for viewing
3) 8 tracks per monitor, 16 monitors on one screen
4) View up to 32 beds in real time on one platform
5) View and manage patient data anytime, anywhere in and before the hospital
1) Spo2 sensor & extend cable 1pcs
2) ECG cable 1pcs
3) Cuff &Tube 1pcs
4) Temp probe
5) Power Cbale Line 1pcs
6) Ground Line 1pcs
7) User Manual 1pcs
|
ECG |
|
|
Input |
3/5 wire ECG cable |
|
Lead section |
I II III aVR, aVL, aVF, V |
|
Gain selection |
*0.25, *0.5, *1, *2, Auto |
|
Sweep speed |
6.25mm/s, 12.5mm/s, 25mm/s, 50mm/s |
|
Heart rate range |
15-30bpm |
|
Calibration |
±1mv |
|
Accuracy |
±1bpm or ±1% (select the bigger data) |
|
NIBP |
|
|
Test method |
Oscillometer |
|
Philosophy |
Adult, Pediatric and Neonate |
|
Measurement type |
Systolic Diastolic Mean |
|
Measurement parameter |
Automatic, Continuous measurement |
|
Measurement method Manual |
mmHg or ±2% |
|
SPO2 |
|
|
Display Type |
Waveform, Data |
|
Measurement range |
0-100% |
|
Accuracy |
±2% (between 70%-100%) |
|
Pulse rate range |
20-300bpm |
|
Accuracy |
±1bpm or ±2% (select the bigger data) |
|
Resolution |
1bpm |
|
2-Temperature (Rectal & Surface) |
|
|
Number of channels |
2 channels |
|
Measurement range |
0-50℃ |
|
Accuracy |
±0.1℃ |
|
Display |
T1, T2, TD |
|
Unit |
ºC/ºF selection |
|
Refresh cycle |
1s-2s |
|
Respiration (Impedance & Nasal Tube) |
|
|
Measurement type |
0-150rpm |
|
Accuracy |
±1bm or ±5%, select the bigger data |
|
Resolution |
1rpm |
|
Power requirements: |
|
|
AC: 100 ~ 240V, 50Hz/60Hz |
|
|
DC: Built-in rechargeable battery, |
11.1V 24wh Li-ion battery |
|
Packaging Information |
|
Packing size |
305mm*162mm*290mm |
|
N.W. |
4.5Kgs |
| G.W | 6.3kgs |
 |
